Manufacturer's photos. Where a power lead is pictured, a UK one is provided.
USW-Enterprise-8-PoE Ubiquiti UniFi Switch Enterprise 8 PoE
Description
Description
The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.
The USW Enterprise 8 PoE also features a 1.3' LCM color touchscreen that concisely displays key system and connection insights.
This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) 1.3' LCM color touchscreen with AR switch management
(8) 2.5GbE, 802.3at PoE+ RJ45 ports
(2) 10G SFP+ ports
120W total PoE supply
Wall-mountable (kit included)
* Layer 3 switching will become available in a future firmware update.
Managed with the UniFi Network application: Version 6.3.51 and later
Specifications34 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 200 x 248 x 44 mm / (7.9 x 9.8 x 1.7") |
| Port Layout · 2.5 GbE RJ45 | 8 (All PoE+) / (2.5G/1G/100/10M) |
| Port Layout · 10G SFP+ | 2 / (10G/1G) |
| Max. PoE Output | Up to PoE+ |
| Total PoE Availability | 120W |
| Form Factor | Compact desktop |
| Performance | |
| Switching Capacity | 80 Gbps |
| Total Non-Blocking Throughput | 40 Gbps |
| Forwarding Rate | 60 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 16,000 |
| IPv4 Static Routes | 256 |
| Packet Buffer Size | 1.5 MB |
| Access Lists · IPv4 | 12 |
| Access Lists · MAC | 10 |
| Hardware | |
| PoE Ports · PoE+ | 8 |
| Max. PoE Wattage per Port by PSE · PoE+ | 32W |
| Max. Power Consumption | 30W (Excluding PoE Output) / 150W (Including PoE Output) |
| Power Method | Universal input, 100–240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 150W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet / AR |
| Heat Dissipation | 102.4 BTU/hr (Excluding PoE Output) |
| Weight | 2.4 kg (5.3 lb) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Supported Rack Depth | 400~1200 mm / (15.7-47.2") |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ± 16kV, contact: ± 12kV |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06645-23-08356 |
| Software | |
| Application Requirements · UniFi Network | Version 6.3.51 and later |
