UNVR‑G2 – Ubiquiti UniFi Protect Network Video Recorder G2
Description
Description
The Ubiquiti UniFi Protect Network Video Recorder G2 (UNVR‑G2) is a high‑performance, enterprise‑ready network video recorder designed to power modern UniFi Protect surveillance systems. Built on the UniFi OS platform, the UNVR‑G2 delivers reliable local recording, intelligent analytics and scalable storage for professional camera deployments.
Housed in a compact 1U rack‑mount chassis, the UNVR‑G2 features four 2.5” or 3.5” drive bays supporting flexible RAID configurations for data protection and extended retention. With integrated AI event analytics and support for up to 30 × 4K cameras or 60 × Full HD cameras, it is ideal for growing surveillance environments that require advanced performance without complexity.
An integrated HDMI output enables direct live viewing on a monitor, while high‑speed networking ensures smooth video recording and playback. Managed centrally through UniFi Protect, the UNVR‑G2 provides secure remote access, simple administration and seamless integration with the wider UniFi ecosystem.
Key Features:
- 1U rack‑mount UniFi Protect NVR
- Four HDD bays with RAID support
- Built‑in AI event analytics
- Supports up to 30 × 4K or 60 × Full HD cameras
- HDMI output for live monitoring
- High‑speed network connectivity
Ideal for:
Businesses, retail environments, education facilities, warehouses and professional security installations.
Compatible Products:
UniFi Protect Cameras
UniFi Protect Viewport
UniFi Switch
UniFi OS Consoles
Frequently asked questions2 questions
Does the UNVR‑G2 include hard drives?
Can the UNVR‑G2 be viewed directly on a screen?
Specifications24 specifications · 3 sections
| Overview | |
|---|---|
| Dimensions | 442.4 x 43.7 x 325 mm / (17.4 x 1.7 x 12.8") |
| Managed Cameras | With built-in HDMI Viewport disabled: / (60) HD / (50) 2K / (30) 4K / / With built-in HDMI Viewport in use: / (40) HD / (30) 2K / (20) 4K |
| Max. Simultaneous Viewport Streams | 16 4K cameras |
| Managed Access Hubs | 150+ |
| Storage Capacity | (4) 2.5/3.5" drive bays |
| Networking Interface | (1) 10G SFP+ port / (1) 2.5 GbE RJ45 port |
| Form Factor | Rack Mount (1U) |
| Management Application | UniFi Protect / UniFi Access / UniFi Connect |
| Hardware | |
| Hard Drive Capacity | (4) 2.5/3.5" HDD / SSD support |
| Max. Power Budget for Drives | 75W |
| Max. Power Consumption | 100W |
| Power Method | (1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz / (1) USP-RPS DC input, 11.5V DC |
| Power Supply | AC/DC, Internal PSU, 100W |
| Processor | Qualcomm® Kryo™ CPU built on Arm® Cortex® technology (4 nm) / (1) Prime core (3.2 GHz) / (4) Performance cores (2.8 GHz) / (3) Efficiency cores (2.0 GHz) |
| Memory | 8 GB |
| Management | Ethernet / Bluetooth |
| Weight | 6 kg (13.2 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| Application Requirements · UniFi Protect | Version 7.1.55 or later. |
| Application Requirements · UniFi Access | Version 4.2.16 or later. |
