USW-Flex-XG Ubiquiti UniFi Switch Flex XG
Description
Description
Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE, PoE+ RJ45 input.
The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input.
The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
(1) GbE, 802.3at PoE+ RJ45 input
(4) 10GbE RJ45 ports
Compact, slim housing
Can be powered with a 5V, 5A USB-C adapter
*Fanless Switch, Do not stack other hardware on the USW Flex XG, will affect heat dissipation
Specifications26 specifications · 4 sections
| Overview | |
|---|---|
| Dimensions | 135 x 185 x 32 mm / (5.3 x 7.3 x 1.3") |
| Port Layout · 1 GbE RJ45 | 1 / (1G/100M/10M) |
| Port Layout · 10 GbE RJ45 | 4 |
| Form Factor | Compact desktop, wall |
| Performance | |
| Switching Capacity | 82 Gbps |
| Total Non-Blocking Throughput | 41 Gbps |
| Forwarding Rate | 61 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 16,000 |
| Packet Buffer Size | 1.5 MB |
| Access Lists · IPv4 | 12 |
| Access Lists · MAC | 10 |
| Hardware | |
| Max. Power Consumption | 25W |
| Power Method | (1) PoE+ / (1) USB Type-C, 5V DC, 5A |
| Power Input Method | USB Input / PoE |
| Power Supply | AC/DC, external, 25W |
| Supported Voltage Range | 4.8—5.2V DC/USB / 44V—57V PoE |
| Management | Ethernet |
| Heat Dissipation | 85.3 BTU/hr |
| Weight | 1.2 kg (2.7 lb) |
| Enclosure Material | Polycarbonate |
| ESD Protection | Air: ± 16kV, contact: ± 12kV |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06606-25-08356 |
| Software | |
| Application Requirements · UniFi Network | Version 6.1.67 and later |
